Expert Handset Data Sheet

With a modern, clear design, ‘Expert’ is a high-end enterprise IP phone for business users who need immediate access to all of their important information.


In addition to a 7-inch capacitive touch screen for up to 116 DSS key entries, the telephone also features 20 SIP lines, HD audio with Opus support, Built-in Bluetooth, Wi-Fi connectivity (Via Wi-Fi dongle) and more!

Highlights

  • 20 SIP lines
  • HD audio on speakerphone and handset
  • 7 inch capacitive touch screen
  • Built-in Bluetooth for connecting Bluetooth headset
  • Wi-Fi connectivity(Via Wi-Fi dongle)
  • Up to 116 DSS keys entries available at the display
  • Video Codec H.264 support for receiving video calls
  • Dual Gigabit ports, integrated PoE
  • Stand with 2 adjustable angles of 40 and 50 degrees

Specifications

Generic

  • 20 SIP Lines
  • HD Voice
  • Support receiving Video call
  • PoE Enabled
  • 7 inch capacitive touch screen
  • Handset / Hands-free / Headset mode
  • Intelligent DSS Keys
  • Optional External Power Supply Phone Features
  • Local Phonebook (2000 entries)
  • Remote Phonebook (XML/LDAP, 2000 entries)
  • Call logs (In/out/missed, 1000 entries)
  • Blocked /Allowed List
  • Screen saver
  • Voice Message Waiting Indication (VMWI)
  • Programmable DSS/Soft keys
  • Network Time Synchronization
  • Built-in Bluetooth 4.2: Support Bluetooth headset
  • Support Wi-Fi Dongle
  • Support Plantronics wireless headset (Through Plantronics APD-80 EHS Cable)
  • Support Jabra wireless headset (Through EHS20 EHS Cable)
  • Support Recording (Through Flash Drive or Server Recording)
  • Action URL / Active URI
  • uaCSTA

Call Features

  • Call out / Answer / Reject
  • Mute / Unmute (Microphone)
  • Call Hold / Resume
  • Call Waiting
  • Intercom
  • Caller ID Display
  • Speed Dial
  • Anonymous Call (Hide Caller ID)
  • Call Forwarding (Always/Busy/No Answer)
  • Call Transfer (Attended/Unattended)
  • Call Parking/Pick-up (Depending on server)
  • Redial
  • Do-Not-Disturb
  • Auto-Answering
  • Voice Message (On server)
  • 6-way Conference
  • Hot Line
  • Hot desking

Video

  • Video codec: H.264
  • Video call resolution: QCIF / CIF / VGA/1080P
  • Support USB camera (CM60 optional)

Audio

  • HD Voice Microphone/Speaker (Handset/Hands-free, 0 ~ 7KHz Frequency Response)
  • HAC handset
  • Wideband ADC/DAC 16KHz Sampling
  • Narrowband Codec: G.711a/u, G.723.1, G.726-32K, G726-16,G726-24,G726-40,G.729AB, iLBC
  • Wideband Codec: G.722, Opus
  • Full-duplex Acoustic Echo Canceller (AEC)
  • Voice Activity Detection (VAD) / Comfort Noise Generation (CNG) / Background Noise Estimation (BNE) / Noise Reduction (NR) / Automatic Gain Control (AGC)
  • Packet Loss Concealment (PLC)
  • Dynamic Adaptive Jitter Buffer up to 300ms
  • DTMF: In-band, Out-of-Band – DTMF-Relay(RFC2833) / SIP INFO

Networking

  • Physical: 10/100/1000 Mbps Ethernet, dual bridged port for PC bypass
  • IP Mode:IPv4/IPv6/IPv4&IPv6
  • IP Configuration: Static / DHCP / PPPoE


  • Network Access Control: 802.1x
  • VPN: L2TP / OpenVPN
  • VLAN
  • LLDP
  • QoS
  • RTCP-XR(RFC3611),VQ-RTCPXR(RFC6035)
  • WI-FI Security Mode：WPA /WPA2-PSK/802.X EAP
  • Protocols
  • SIP2.0 over UDP/TCP/TLS
  • RTP/RTCP/SRTP
  • STUN
  • DHCP
  • IPv6
  • LLDP
  • PPPoE
  • 802.1x
  • L2TP
  • OpenVPN
  • SNTP
  • FTP/TFTP
  • HTTP/HTTPS
  • TR-069
  • AES128 & AES256
  • Deployment & Maintenance
  • Auto-Provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP PNP/TR-069
  • Web Management Portal
  • Web-based Packet Dump
  • Configuration Export / Import
  • Phonebook Import/Export
  • Firmware Upgrade
  • Syslog
  • Physical Specifications
  • Main LCD x1: 7.0 inch (1024x600) Capacitive touch screen
  • Keypad: 26 keys, including
  • 5 Function keys (Hold, MWI,Mute,Headset, Redial)
  • 4 Navigation keys
  • 1 OK key
  • 1 Return key
  • 12 Standard Phone Digits keys
  • 2 Volume Control keys, Up/Down
  • 1 Hands-free key
  • HD Handset (RJ9) x1
  • Standard RJ9 Handset Wire x1
  • 1.5M CAT5 Ethernet Cable x1
  • Back Rack x1
  • RJ9 Port x2: Handset x1, Headset x1
  • RJ45 Port x2: Network x1, PC x1 (Bridged to Network)
  • USB2.0 Port x1: Standard A, Connect with Wi-Fi USB dongle or Flash Driver
  • DC Power Input: 5V/2A
  • Power Consumption (PoE): 2.6~ 9W
  • Power Consumption (Adapter): 2.4~8W
  • Working Temperature: 0~45℃
  • Working Humidity: 10~95%
  • Qty/CTN：10pcs
  • N.W/CTN: 16.6kg
  • G.W/CTN: 17.72kg
  • Installation:
  • Desktop
  • Stand
  • Color: Black
  • Device Dimensions
  • Desktop Stand (Angles 1): 268 x 185 x 189mm
  • Desktop Stand (Angles 2): 268 x 201 x 168mm
  • Gift Box Dimensions: 304 x 297 x 66mm
  • Outer CTN Dimensions: 616 x 358 x 329mm (10 PCS)
